50KW/6000rpm, Chery 1100cc Water-Cooled Engine, 4unit/40HQ Mini Off Road Buggy 1100TR-T4
Our vehicles satisfy the EPA standard, they are very popular in American market. With the original Chery 1100cc water-cooled engine, this model has a powerful and stable PTO. It use manual 5-speed-hydraulic transmission, with 2WD/4WD front and rear locking differential. The front suspension (independent, double swing arm) and rear suspension (independent, trailing dual swing arm) makes the vehicle very stable. And the option part luxury absorber shock makes the driving even more pleasant. This model use hydraulic four wheel brake disc, so it has more powerful braking ability. Also the luxurious aluminum rim (patented design), wide luxurious seat will make you feel comfortable during a long drive. And we provide various option parts e.g. spotlight, roof rack, canvas cab, plastic cab, simple windscreen, new front bumper, luxury shock, entire vehicle cover, winch, etc. Considering different road condition, it also has off road tire, road tire to choose.
Specifications:
spec 1100TR-T4
Length*width*heigth 4020x1600x1990(mm)
net weight(kg) 870
carrying capacity(kg) 500
wheelbase(mm) 3250
front-wheel gauge(mm) 1360
rear-wheel gauge(mm) 1430
turning circle diameter(m) ﾡￜ10
ground clearance(mm) 300
fuel tank(L) 28
top speed(km/h) 80
front suspension independent,double swing arm
rear suspension independent,trailing dual swing arm
front,rear brake hydraulic four wheel disc
tire "27ﾡ8-14ﾣﾨfrontﾣﾩ
27ﾡ11-14ﾣﾨrearﾣﾩ"
transmission manual 5-speed-hydraulic clutch
drive systerm 2WD/4WD front and rear locking differential
engine "Chery
SQR472"
engine type In-line four cylinder,16-valve DOHC,water-cooled
bore X stroke 72x66.5
displacement 1080
compressure ratio 9.5:1
carburetor "ﾣﾨEFI)
electronic fuel injection"
ignition ECU
rated power 50KW/6000rpm(68HP)
max torque 90N.m/4000rpm
color red,white,yellow,blue,black,army green
option parts spotlight,roof rack,canvas cab,plastic cab,simple windscreen,new front bumper,lux shock,entire vehicle cover,winch
tire choise offroad tire, road tire
packing size 4125x1810x1150(mm)
qty/container 2unit/20GPﾣﾻ4unit/40GPﾣﾻ4unit/40HQﾣﾻ6unit/45HQ
|
spec |
1100TR-T4 |
|
Length*width*heigth |
4020x1600x1990(mm) |
|
net weight(kg) |
870 |
|
carrying capacity(kg) |
500 |
|
wheelbase(mm) |
3250 |
|
front-wheel gauge(mm) |
1360 |
|
rear-wheel gauge(mm) |
1430 |
|
turning circle diameter(m) |
≤10 |
|
ground clearance(mm) |
300 |
|
fuel tank(L) |
28 |
|
top speed(km/h) |
80 |
|
front suspension |
independent,double swing arm |
|
rear suspension |
independent,trailing dual swing arm |
|
front,rear brake |
hydraulic four wheel disc |
|
tire |
27×8-14(front)
27×11-14(rear) |
|
transmission |
manual 5-speed-hydraulic clutch |
|
drive systerm |
2WD/4WD front and rear locking differential |
|
engine |
Chery
SQR472 |
|
engine type |
In-line four cylinder,16-valve DOHC,water-cooled |
|
bore X stroke |
72x66.5 |
|
displacement |
1080 |
|
compressure ratio |
9.5:1 |
|
carburetor |
(EFI)
electronic fuel injection |
|
ignition |
ECU |
|
rated power |
50KW/6000rpm(68HP) |
|
max torque |
90N.m/4000rpm |
|
color |
red,white,yellow,blue,black,army green |
|
option parts |
spotlight,roof rack,canvas cab,plastic cab,simple windscreen,new front bumper,lux shock,entire vehicle cover,winch |
|
tire choise |
offroad tire, road tire |
|
packing size |
4125x1810x1150(mm) |
|
qty/container |
2unit/20GP；4unit/40GP；4unit/40HQ；6unit/45HQ |
